| Frame: | All New ePantera Alloy 29” Frame, Shimano STEPS Specific, Internal Battery, Tapered Head Tube, Boost 12x148 Thru Axle |
|---|
| Fork: | SR Suntour XCM, 100mm, Coil, 46mm offset |
|---|
| Headset: | FSA NO.57E, Zero Stack, Sealed Bearing |
|---|
| Stem: | 6061 Alloy, 31.8, 7° |
|---|
| Handlebar: | All Terra Riser, 6061 alloy, 15mm rise, 8° sweep, 4° rise, 740mm width |
|---|
| Front Brake: | Tektro M275 Hydro Disc, 180/180mm Rotors |
|---|
| Rear Brake: | Tektro M275 Hydro Disc, 180/180mm Rotors |
|---|
| Brake Lever: | Tektro M275 |
|---|
| Rear Mech: | microSHIFT RD-M36L |
|---|
| Shifters: | microSHIFT TS39-8, 8-speed |
|---|
| Speed: | 8 |
|---|
| Rims: | WTB STX i25 TCS, 32h, tubeless ready |
|---|
| Front Hub: | Formula DC-511, 15x110 |
|---|
| Rear Hub: | Formula, QR |
|---|
| Spokes: | Stainless Steel, 14g |
|---|
| Front Tyre: | Schwalbe G-One Allround Performance, 29 x 2.25", RaceGuard, tubeless ready |
|---|
| Rear Tyre: | Schwalbe G-One Allround Performance, 29 x 2.25", RaceGuard, tubeless ready |
|---|
| Seat Post: | All Terra, 6061 alloy, 0mm offset, 30.9, 350mm (XS-M), 400mm (L-XL) |
|---|
| Saddle: | WTB Silverado Sport, Steel rails |
|---|
| Chainset: | Shimano FC-E5010, 165mm, 36T |
|---|
| Chain: | Shimano HG71 |
|---|
| Cassette: | microSHIFT, 11-36T |
|---|
| Pedals: | GT Plastic OPC Body |
|---|
| Battery Size (WH): | Shimano STEPS BT-E8035, 504Wh |
|---|
| Motor: | Shimano STEPS DU-E5000 250W |
|---|
| Frame Size: | 16" (S) / 19" (L) |
|---|
| User Interface: | Bluetooth connection box EW-EN100 |
|---|
